- Fully Approved Explosion-Proof Annunciators
- Switch, Open Collector NPN Transistor, and Logic Level Inputs
- 4-Point Monitoring
- 8 Field Selectable ISA Sequences Including First-Out
- Multiple-Unit First-Out Indication
- Free Custom Message Labels
- Silence, Acknowledge, and Reset Functions
- Sunlight Readable Indication
- CapTouch Through-Glass Button Programming
- Annunciator Mountable at 0°, 90°, 180°, & 270°
- 24 VDC @ 200 mA Power Available to Drive Other Devices (AC Models)
- 2 SPDT Relays for Alarm Activated Devices
- Operating Temperature Range: -55 to 65°C (-67 to 149°F)
- CSA Certified as Explosion-Proof / Dust-Ignition-Proof / Flame-Proof
- ATEX and IECEx Certified as Dust-Ignition-Proof / Flame-Proof
- Input Power Options Include 85-265 VAC or 12-36 VDC
- Built-in internal Audible Alarm with Silence Pushbutton
- Flanges for Wall or Pipe Mounting
- Explosion-Proof Aluminum or Stainless Steel NEMA 4X / IP68 Enclosures
- Four 3/4" NPT Threaded Conduit Openings
- Pipe Mounting Kits
- Stainless Steel Tag Available
- 3-Year Warranty
** NEW IMPROVED WEB STORE! | All users must register for a new account. | Register now > **
BUY ONLINE TO SAVE TIME AND INCREASE ORDER ACCURACY!
Questions? (508) 655-7300
ProtEX-MAX Explosion-Proof Alarm Annunciators
PD8-150 Series - Available in Aluminum or Stainless Steel Enclosures
Models in stock
from $1508.00
The ProtEX-MAX PD8-154 offers all the functionality of the Vigilante II PD154 as a CSA, ATEX, and IECEx certified explosion-proof product. It is available in an aluminum or stainless steel enclosure and will operate over a wide temperature range of -55 to 65°C (-67 to 149°F). It provides alarming and monitoring capabilities for all of your level, pressure, flow, and other process switches. The PD8-154 has four (4) inputs and accepts inputs from relays, float switches, digital outputs, and many other discrete (on/off) devices. It can be field programmed for all common ISA alarm sequences including first out indication and provide alarm signaling through front panel LEDs and a built in 85 dB horn. The silence, acknowledge, and reset functions can be operated without opening the housing by using the built-in CapTouch through-glass buttons. Custom printed message labels can be included with your order at no additional charge.
Why Should You Buy:
- Worldwide Explosion-Proof Approvals
- 4-Point Monitoring
- All Common ISA Sequences
